Fire Pump Set
AQUAPUMP

Fire Pump Set

  • Volute Casing: Cast Iron
  • Impeller, Wear Ring: Bronze
  • Shaft: Stainless Steel
  • Shaft Sleeve: Stainless Steel
  • Seal: Teflon Packing – Mechanical
  • Bearing: FAG/SKF Grease Lubricated
  • Operating Temperature: -10 °C to +120 °C
  • Standards: TS EN 12845+A1, NFPA 20
  • Pump Types: Horizontal-Shaft Centrifugal, Double-Suction, Two-Stage, Jockey
DOCUMENTS →
AQUAPUMP

Capacity and Dimension Tables

Model-Pump Jockey Pump Main Pump (kW) Standby Pump (kW) Jockey (kW) Avg. m³/h (GPM) Avg. m Max. m³/h (GPM) Max. m
ASTY-21EJ 32-250 ASN 80-1011 7,5 7,5 1,5 11,4 (50) 60 17,1 (75,3) 55
ASTY-21EJ 32-250 ASN 80-1011 11 11 1,5 11,4 (50) 70 17,1 (75,3) 65
ASTY-21EJ 32-250 ASN 80-1012 15 15 1,5 11,4 (50) 85 17,1 (75,3) 80
ASTY-21EJ 32-250 ASN 80-1012 18,5 18,5 1,5 11,4 (50) 90 17,1 (75,3) 90
ASTY-21EJ 40-250 ASN 90-2008 15 15 3 22,7 (100) 75 34,1 (150,2) 70
ASTY-21EJ 40-250 ASN 90-2008 18,5 18,5 3 22,7 (100) 85 34,1 (150,2) 80
ASTY-21EJ 40-250 ASN 90-2009 22 22 3 22,7 (100) 90 34,1 (150,2) 90
ASTY-21EJ 40-250 ASN 90-2009 30 30 3 22,7 (100) 105 34,1 (150,2) 100
ASTY-21EJ 50-250 ASN 90-2008 22 22 3 45,4 (200) 60 68,1 (300) 55
ASTY-21EJ 50-250 ASN 90-2008 30 30 3 45,4 (200) 70 68,1 (300) 65
ASTY-21EJ 50-250 ASN 90-2009 37 37 3 45,4 (200) 95 68,1 (300) 90
ASTY-21EJ 50-250 ASN 90-2009 45 45 3 45,4 (200) 100 68,1 (300) 100
ASTY-21EJ 50-250 ASP 416 45 45 3 45,4 (200) 115-120 68,1 (300) 110
ASTY-21EJ 50-250 ASP 416 55 55 3 45,4 (200) 125-130 68,1 (300) 120
ASTY-21EJ 65-250 ASN 90-2008 30 30 3 68,1 (300) 60 102,2 (450) 55
ASTY-21EJ 65-250 ASN 90-2008 37 37 3 68,1 (300) 75 102,2 (450) 65
ASTY-21EJ 65-250 ASN 90-2009 45 45 3 68,1 (300) 80 102,2 (450) 80
ASTY-21EJ 65-250 ASN 90-2009 55 55 3 68,1 (300) 95 102,2 (450) 90
ASTY-21EJ 65-250 ASP 814 55 55 5,5 68,1 (300) 115-120 102,2 (450) 105
ASTY-21EJ 65-250 ASP 814 75 75 5,5 68,1 (300) 125-130 102,2 (450) 110
ASTY-21EJ 65-250 ASN 90-2008 45 45 3 91 (400) 80 136 (600) 60
ASTY-21EJ 65-250 ASN 90-2009 55 55 3 91 (400) 90 136 (600) 75
ASTY-21EJ 65-250 ASN 90-2009 55 55 3 91 (400) 100 136 (600) 85
ASTY-21EJ 65-250 ASP 416 55 55 3 91 (400) 115-120 136 (600) 110
ASTY-21EJ 65-250 ASP 416 75 75 3 91 (400) 125-130 136 (600) 120
ASTY-21EJ 80-250 ASN 90-2008 45 45 5,5 113,6 (500) 65 170,4 (750) 55
ASTY-21EJ 80-250 ASN 90-2008 55 55 5,5 113,6 (500) 70 170,4 (750) 65
ASTY-21EJ 80-250 ASN 90-2009 75 75 5,5 113,6 (500) 80 170,4 (750) 80
ASTY-21EJ 80-250 ASN 90-2009 90 90 5,5 113,6 (500) 100 170,4 (750) 95
ASTY-21EJ 80-250 ASP 814 90 90 5,5 113,6 (500) 120 170,4 (750) 110
ASTY-21EJ 80-250 ASP 814 110 110 5,5 113,6 (500) 130 170,4 (750) 125
ASTY-21EJ 100-250 ASN 100-3006 75 75 5,5 170,4 (750) 80 255 (1125) 70
ASTY-21EJ 100-250 ASN 100-3006 90 90 5,5 170,4 (750) 90 255 (1125) 80
ASTY-21EJ 100-250 ASN 100-3006 110 110 5,5 170,4 (750) 95 255 (1125) —
ASTY-21EJ 100-250 ASP 814 110 110 5,5 170,4 (750) 110 255 (1125) 100
ASTY-21EJ 100-250 ASP 814 132 132 5,5 170,4 (750) — 255 (1125) 110
